DIY-P88

About Perkins

With a history stretching back more than 85 years, Perkins is one of the world’s leading providers of diesel engines. We aim to set standards of engineering excellence, providing the most comprehensive range of innovative and reliable power solutions, tailored to meet the precise requirements of our customers.

General characteristics – 6 & 12 wire

Ratings 50 Hz-1500 R.P.M.-6& 12-wire

Compliance with internationally recognized standards

Compliance with internationally recognized standards

4 Pole Alternators are in compliance to the main international standards and regulations:

-IEC 60034, NEMA MG 1.32-33, BS 5000 Part 99, VDE 0530, ISO 8528/3, UL 1446, UL 1004 on

request and depending on voltages, marin regulations, etc. It can be integrated into a CE marked

generator.

Alternators are designed, manufactured and marketed in an ISO 9001 and ISO14001 environments

Electrical design

● The alternators are IP 23

● Class H insulation

● Low voltage winding

● 4-terminal plate

● Optimized performance

Robust design

● Compact and rugged assembly to withstand engine vibrations

● Steel frame

● Aluminum flanges and shields

● Single-bearing design to be suitable with most diesel engines

● Sealed for life bearing

● Direction of rotation: clockwise

Integrating digital, intelligent and network techniques are used for automatic control system of diesel generator. It can carry out functions including automatic start/stop, data measure and alarming.



AMF Function:

Upon detection of a mains (utility) failure the module automatically starts the generating set. Once the mains (utility) power has been restored it instructs the generating set to stop.

1. Control Module:  MRS10,  AMF9, DSE7320 for standard controller

～ MRS16, AMF25, DSE7420 for optional

2. DC Power Switch for control system

3. Emergency Stop Button

4. Breaker Handle & Window for operated from outside

5. U/ V/ W Live wire terminals (Copper Bars)

6. N Neutral wire terminals (Copper Bar)

7. (ATS/ Main Power/ Remote Control...etc. ) Signals Access Terminals

Standard Control Panel -ComAp IL3-AMF9

Main Features:

Δ Single gen-set controller for stand-by and prime-power applications

Δ Direct communication with EFI engines

Δ All-in-one intuitive & powerful PC tool for configuration/monitoring/control, locally or remotely

Δ Stand-by and prime-power application in one unit

Δ 5 languages in the controller & Translator functionality, 3 levels of passwords,3 sets of alternative configurations

Δ Magnetic pickup, ECU support & Tier 4 Final ready, 1 slot for plug-in modules

Δ Plug-in module concept for more capabilities (Modbus, Internet, SMS, inputs/outputs)

Δ Power over USB for controller’s adjustment, Adjustable D+ threshold, Ventilation pulse

Δ 6 binary outputs, 6+1 binary inputs, 3 analog inputs,2 high-current binary outputs

Δ E-Stop input physically disconnets binary outputs 1 & 2 from power, Adjustable delay for binary inputs

Δ Alarms and gen-set status asignable to binary outputs

Δ Possibility to select the source for Run Hours, real time clock

Δ Warm-up and cooling functions

Δ Generator C.B. and Mains C.B. control with feedback and return timer

Δ Multi-purpose scheduler functionality, 3 maintenance timers

Δ Detailed history log with up to 150 records, Zero power mode

Δ Start on low battery

Δ Cutout: 172mm x 112 mm (same as IL-NT family)

Other Brands of Control Moudle Opitional
