DLT-5000 series light tower from Brighter Electromechanical provide versatile, low maintenance, durable and reliable lighting. DLT-5000 series light tower offers light and up to 8kw of export power for jobsite power need all in a compact footprint. The light tower is rugged, weather-resistant and impact-resistant in all-steel body. It’s hood is covered with acid and alkali resistant paint and easy to clean.
Light coverage m2：4.000 (average 20 luxes)
Lamps | Halogen lamps |
Mast | laydown or vertical manual |
Feartures | Powder coat canopy |
Performance Data | ||
Rated Frequency | HZ | 50/60 |
Rated Voltage | VAC | 230/120 |
Rated Power(PRP) | KW | 6/8 |
Operating Temperature(min/max) | ℃ | -25~50 |
Sound Pressure Level@1m | dB(A) | 90 |
Sound Power @7m | dB(A) | 65 |
Power output | ||
Auxiliary Power | KW | 2/4 |
Lights | ||
Floodlights | Halogen lamps | |
Wattage | W | 4 x 1000 |
Mast | ||
Type | Manual | |
Rotation | Degrees | 360 |
Maximum Height | m | 9 or 8 |
Maximum Speed wind | km/h | 80 |
Enclosure and Trailer | ||
Type | Ball or hitch fix or adjustable towbar or site trailer with leaf or rubber suspension | |
Base Frame | ||
Enclosure | Steel canopy and powder coating paint | |
Dimensions and weight | ||
Dimensions in transport fix towbar(L*W*H) | m | 1,9 x 1,29x1,63 |
Weight | kg | 800 |
Engine | ||
Model | Kubota D1105-E2BG | |
Speed | RPM | 1500/1800 |
Rated Net Output(PRP) | KW | 8.4/9.5 |
Coolant | Water | |
Number of cylinders | 3 | |
Alternator | ||
Model | DIY164G65 | |
Rated output | KVA | 6/8 |
Insulation/Enclosure protection | Class/IP | H/23 |
Consumption | ||
Fuel tank capacity | Litre | 100 |
Runtime before with lamps ON | hrs | 60 |
Engine: Kubota, Perkins, Yanmar, Yangdong
Alternator: Stamford, Leroy-Somer, DIY high quality copy Stamford
Lights: Halogen lamps, LED
Mast: Manual, Hydraulic
Folder: laydown， vertical
Maximum Height: 6m, 8m, 9m, 10m
Spare Parts: 500 hours, 1000 hours，3000 hours
